Camera
Image Sensor
1/2.7" CMOS
Effective Pixels
2560(H)×1440(V), 4MP
Scanning System
Progressive
Electronic Shutter Speed
PAL: 1/25~1/100000s
NTSC: 1/30~1/100000s
Minimum Illumination
0.04Lux/F2.0, 30IRE, 0Lux IR on
S/N Ratio
More than 65dB
IR Distance
Up to 20m (66feet)
IR On/Off Control
Auto / Manual
Lens
Lens Type
Fixed lens / Fixed iris
Mount Type
Board-in
Focal Length
3.6mm (2.8mm, 6mm Optional)
Max Aperture
F2.0
Angle of View
2.8mm: 125° x105° x56° (diagonal x horizontal x vertical) 3.6mm: 107° x 89° x 48° (diagonal x horizontal x vertical) 6mm: 61° x 54° x 31° (diagonal x horizontal x vertical)
Focus Control
N/A
Close Focus Distance
2.8mm:0.7m(2.3 ft) 3.6mm:1.1 m (3.6 ft) 6mm: 2.7 m (8.9 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8mm
49.8 m
(163.0 ft)
19.9 m
(65.0 ft)
10.0 m
(33.0 ft)
5.0 m
(17.0 ft)
3.6mm
64.0 m
(210.0 ft)
25.6 m
(84.0 ft)
12.8 m
(42.0 ft)
6.4 m
(21.0 ft)
6mm
106.7 m
(350.0 ft)
42.7 m
(140.0 ft)
21.3 m
(70.0 ft)
10.7 m
(32.0 ft)
Pan / Tilt / Rotation
Pan/Tilt/Rotation
Pan: 0° ~ 360° Tilt: 0° ~ 78° Rotation: 0° ~ 360°
Video
Resolution
4MP (2560×1440)
Frame Rate
25/30fps@4MP,25/30fps@1080P
Video Output
1-channel BNC high definition video output / CVBS video output (Can switch)
Day/Night
Auto (ICR) / Manual
OSD Menu
Multi-language
BLC Mode
BLC / HLC / DWDR
WDR
DWDR
Gain Control
AGC
Noise Reduction
2D
White Balance
Auto / Manual
Smart IR
Auto / Manual
Certifications
Certifications
CE (EN55032, EN55024, EN50130-4)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
Interface
Audio Interface
N/A
Eelectrical
Power Supply
12V DC ±30%
Power Consumption
Max. 2.6W (12V DC, IR on)
Environmental
Operating Conditions
-40°C ~ +55°C (-40°F ~ +131°F) / Less than 95% RH
* Start up should be done at above -40°C (-40°F)
Storage Conditions
-40°C ~ +55°C (-40°F ~ +131°F) / Less than 95% RH
Ingress Protection & Vandal Resistance
NA
Construction
Casing
Plastic
Dimensions
85mm×85mm×69mm(3.35"×3.35"×2.72")
Net Weight
0.09kg (0.20lb)
Gross Weight
0.13kg (0.27lb)
